MV-SC3050XC-35M-WBN

MV-SC3050XC-35M-WBN

SC3000X series vision sensor，35mm focal length，5MP，Color
Key Features
  • Uses an embedded hardware platform for high-speed image processing.
  • Built-in high-precision algorithms for counting, defect detection, presence, positioning and other functions.
  • Supports RS-232, TCP, UDP, FTP, ModBus, PROFINET, EtherNet/IP and other communication modes.
  • Uses multiple I/O interfaces for input and output signals.
  • Real-time device status monitoring with a 360° visual indicator, convenient for debugging and maintenance.
  • Rotatable cable outlet design suitable for narrow spaces.
  • Uses polarised, diffuse and fully transparent multi-optical illumination with high environmental adaptability.
  • Operates safely in harsh industrial environments with IP67 protection.
Detailed Parameters
ModelMV-SC3050XC-35M-WBN
TypeSC3000X series vision sensor，35mm focal length，5MP，Color
Sensor TypeCMOS, global shutter
Piksel Boyutu3.45 μm × 3.45 μm
Sensor Size1/1.8″
Resolution2592 × 1944
Max. Frame Rate35 fps
Dynamic Range73.4 dB
Signal/Noise40.5 dB
Gain0 dB to 15 dB
Exposure Time6 μs to 1 sec
Pixel FormatBayerRG 8, BayerRG 10, BayerRG 12
Mono/RenkliColor
Data InterfaceFast Ethernet (100 Mbit/s)
Digital I/O12-pin M12 connector; opto-isolated input (LINE 0/1/2) × 3, opto-isolated output (LINE 3/4/5) × 3, RS-232 × 1
Power Supply24 VDC
Max. Power ConsumptionApprox. 7 W@24 VDC
Lens MountM12-mount, mechanical autofocus supported
Focal Length35mm
Light SourceWhite spot light source; Red/Blue/IR optional
Indicator360° visual indicator
DimensionsStraight: 80.1 mm × 43 mm × 44.3 mm / Right angle: 58.5 mm × 43 mm × 65.4 mm
WeightApprox. 190 g
Protection ClassIP67
Operating Temperature0 °C to 50 °C
Storage Temperature-30 °C to 70 °C
Humidity20% to 95% RH, non-condensing
Client SoftwareSCMVS
CertificationCE, KC
Communication ProtocolRS-232, TCP, UDP, FTP, PROFINET, ModBus, EtherNet/IP, MELSEC/SLMP, FINS, Keyence KV
