MV-SC3013C-16M-WBN

MV-SC3013C-16M-WBN

SC3000 series vision sensor，16mm focal length，1.3MP，Color
Key Features
  • Uses an embedded hardware platform for high-speed image processing.
  • Built-in high-precision algorithms for counting, defect detection, presence, positioning and other functions.
  • Supports RS-232, TCP, UDP, FTP, ModBus, PROFINET, EtherNet/IP and other communication modes.
  • Uses multiple I/O interfaces for input and output signals.
  • Real-time device status monitoring with a 360° visual indicator, convenient for debugging and maintenance.
  • Rotatable cable outlet design suitable for narrow spaces.
  • Uses polarised, diffuse and fully transparent multi-optical illumination with high environmental adaptability.
  • Operates safely in harsh industrial environments with IP67 protection.
Detailed Parameters
ModelMV-SC3013C-16M-WBN
TypeSC3000 series vision sensor，16mm focal length，1.3MP，Color
Sensor TypeCMOS, global shutter
Resolution1216 × 1024
Max. Frame Rate60 fps
Gain0 dB to 15 dB
Exposure Time6 μs to 1 sec
Pixel FormatBayerRG 8, BayerRG 10, BayerRG 12
Mono/RenkliColor
Data InterfaceFast Ethernet (100 Mbit/s)
Digital I/O12-pin M12 connector; I/O ports for input and output signals
Power Supply24 VDC
Lens MountM12-mount
Focal Length16mm
Light SourceWhite LED
Dimensions80.1 mm × 43 mm × 44.3 mm
WeightApprox. 190 g
Protection ClassIP67
Operating Temperature0 °C to 50 °C
Humidity20% to 95% RH, non-condensing
Client SoftwareSCMVS
CertificationCE, KC
Communication ProtocolRS-232, TCP, UDP, FTP, PROFINET, ModBus, EtherNet/IP
