ADVANTECH WISE-6610 V2 — Vibration Sensors
Industrial LoRaWAN gateway with the Semtech SX1302 chipset, an embedded LoRaWAN network server (up to 500 nodes), Modbus/TCP and MQTT support, DIN-rail/wall mounting; −40 to +75 °C.
Status: In production
Product: Industrial LoRaWAN gateway
Wireless: LoRaWAN · SX1302 · IN865/EU868/AU915/US915/KR920/AS923/CN470
Network: 2 × 10/100 Mbps RJ45 · 2 × nano SIM (4G modül isteğe bağlı)
Software: Embedded LNS, Node-RED, Modbus/TCP, MQTT; -EL: Edgelink, BACnet, OPC UA
Power / environment: 9 – 36 V DC · IP30 · −40…+75 °C
WISE-6610 V2 is Advantech’s next-generation industrial LoRaWAN gateway. The Semtech SX1302 chipset doubles packet-processing speed over the previous generation; the embedded LoRaWAN network server (LNS) resolves up to 500 node connections directly on the device, so data from sensors such as the WISE-2410 can be passed to SCADA and higher-level systems via Modbus/TCP or MQTT without a cloud server. It is also compatible with external network servers such as Actility, The Things Network, ChirpStack and AWS.
Node-RED runs on the ARM Cortex-A8 1 GHz processor with 4 GB DDR3 memory and 16 GB eMMC storage; the -EL ordering codes add BACnet/IP and OPC UA via the Edgelink software. DHCP, NAT, VLAN, QoS, OSPF/BGP/RIP routing, HTTPS/SSH, a firewall and OpenVPN/IPsec/L2TP/GRE VPN tunnels provide secure communication; two nano-SIM slots offer a 4G backhaul with the optional LTE Cat 4 module. 150 × 37.5 × 83 mm, 500 g, DIN-rail or wall mounting; ordering codes -NB (NA915), -EB (EU868), -TB (AS923), -JB (JP923) and -CB (CN470) follow the frequency plan.
Technical specifications
| WISE-6610 V2 | |
|---|---|
| System | |
| CPU | ARM Cortex-A8, 1000 MHz |
| RF chip | Semtech SX1302 |
| Memory | 4 GB DDR3 |
| Internal storage | 16 GB eMMC |
| WSN support | |
| Standard | LoRaWAN |
| Network mode | AP / Repeater |
| Transmit power | 13,94 dBm (CE) / 25,17 dBm (FCC) |
| Frequency | IN865 / EU868 / AU915 / US915 / KR920 / AS923 / CN470 |
| Antenna connector | 1 × RP-SMA erkek |
| Antenna gain | 2,23 dBi (868 MHz) / 0,67 dBi (915 MHz) / 2,9 dBi (928 MHz) |
| LAN interface | |
| Ethernet | 10/100 Mbps, auto MDI/MDIX |
| Connector | 2 × RJ45 |
| Protection | 1.5 kV built-in magnetic isolation |
| Software | |
| Network and routing | DHCP server, NAT/PAT, VRRP, dynamic DNS client, DNS proxy, VLAN, QoS, DMVPN, NTP client/server, IGMP, BGP, OSPF, RIP, SMTP/SMTPS, SNMP v1/v2c/v3, backup routers, PPP, PPPoE, SSL, port forwarding, host port routing, Ethernet bridging, network server |
| Configuration | SSH, Web |
| Network security | HTTPS, SSH, VPN tunnels, SFTP, DMZ, firewall (IP / MAC / port filtering) |
| VPN tunnelling | OpenVPN client/server/P2P, L2TP, PPTP, GRE, EasyVPN, IPsec (IKEv1/IKEv2) |
| Software packages | Node-RED, LoRaWAN network server (up to 500 nodes), Edgelink (only in -EL P/N) |
| Industrial protocols | Modbus/TCP, MQTT; BACnet and OPC UA (-EL) |
| Mechanics | |
| Dimensions (W × H × D) | 150 × 37,5 × 83 mm |
| Mounting | DIN rail, wall |
| Weight | 500 g |
| Enclosure rating | IP30 |
| Card slots | 1 × micro SD · 2 × nano SIM |
| Power and environment | |
| Power input | 9 – 36 V DC |
| Power consumption | typ. 3 W (max. 3.2 W @ 24 V, 4 W @ 12 V) |
| Operating temperature | −40…+75 °C |
| Storage temperature | −40…+85 °C |
| Operating humidity | 10 – 95 % RH |
Key features
- Semtech SX1302 chipset — doubles packet-processing speed
- Embedded LoRaWAN network server for private and public networks (up to 500 nodes)
- Compatible with network servers such as Actility, The Things Network, ChirpStack and AWS
- Modbus/TCP and MQTT; BACnet and OPC UA with -EL P/N
- Built-in Node-RED, LoRaWAN network server and (-EL) Edgelink software
- Global LoRaWAN frequency plans
- DIN-rail and wall mounting
- 4G backhaul via additional adapter
Ordering information
| Part number | Description |
|---|---|
| WISE-6610-NB / -EB / -TB / -JB / -CB | LoRaWAN gateway — NA915 / EU868 / AS923 / JP923 / CN470 MHz |
| WISE-6610-EL-NB / -EL-EB / -EL-TB / -EL-JB / -EL-CB | LoRaWAN gateway + Edgelink — NA915 / EU868 / AS923 / JP923 / CN470 MHz |
| WISE-6610-BTO | Standard P/N with accessories (LoRa antenna and DIN-rail bracket; except CN470 version) |
Accessories and related products
| Part number | Description |
|---|---|
| 96PD-EG25GGB | LTE Cat 4 module with GNSS, global version |
| 1751000428-01 + 1750006264 | Sub-6 GHz LTE antenna + 15 cm SMA(F) cable (2 sets) |
| OPT1-RPS-1212-EU | 12 V / 1 A power supply, EU plug |
| 1751000787-01 | LoRa antenna for 470 – 520 MHz (CN470) |
