ADVANTECH WISE-2410 — Vibration Sensors
Battery-powered LoRaWAN wireless condition-monitoring sensor with an ARM Cortex-M4 processor, integrated 3-axis accelerometer and temperature sensor — ISO 10816/20816-compliant, IP66, for rotating equipment such as motors, pumps and compressors.
Status: In production
Product: LoRaWAN smart vibration sensor
Communication: LoRaWAN (EU868 / US915 / AS923 / JP923 …)
Measurement: 3-axis acceleration + temperature
Power: 2 × 3.6 V AA battery (~2 years at 1 reading/hour)
Protection: IP66 · −20…+80 °C
WISE-2410 is Advantech’s LoRaWAN-based wireless condition-monitoring sensor. The on-board ARM Cortex-M4 processor processes the raw data from the 3-axis accelerometer inside the sensor and sends velocity RMS, acceleration RMS/peak, displacement, kurtosis, crest factor, skewness and standard deviation directly to the application, reducing the load on the gateway and the cloud. Alarm thresholds can be set according to ISO 10816/20816 classes. The sensor also measures equipment surface temperature through its metal base.
Two 3.6 V AA lithium batteries give roughly two years of operation at a one-reading-per-hour interval; the sensor attaches to equipment without cabling via stud, mounting pad/adhesive or magnetic base. Configuration is done over Micro-B USB with the WISE Studio utility. Choose WISE-2410-EB (EU 863-870 MHz) or WISE-2410-NB (US 902-928 MHz; optional firmware patches for JP/AS/KR/AU) according to the regional frequency band; data is collected through a WISE-6610-series LoRaWAN gateway.
Technical specifications
| WISE-2410 | |
|---|---|
| Wireless communication | |
| Standard | LoRaWAN |
| Frequency bands | EU 863-870 / RU 864-870 / US 902-928 / AU 915-928 / AS 919-924 / TH 920-925 / JP 920-928 / TW 920.3-923.4 MHz |
| Spreading factor | SF7 – SF12 |
| Transmit power | up to 20 dBm |
| Topology | Star (LoRa/LoRaWAN) |
| Sensitivity | −148 dB |
| Data rate | 50 kbps (FSK, EU) · 21,9 kbps (SF7, US) · 5,47 kbps (SF7, JP/TW) |
| General | |
| Power input | 2 × 3.6 V AA battery (not included) |
| Battery life | 2 years (one data update per hour) |
| LED indicators | Power, Tx |
| Configuration interface | Micro-B USB |
| IP class | IP66 |
| Mounting | Stud mount, mounting pad and adhesives |
| Dimensions (H × D) | 84,7 × 48,3 mm |
| Certification | CE (RED), FCC, NCC, TELEC, VCCI, BSMI, RCM, ANATEL |
| Environment | |
| Operating temperature | −20 to +80 °C (battery powered) |
| Operating humidity | 10 – 95 % RH |
| Storage temperature | −25…+90 °C |
| Storage humidity | 5 – 95 % RH |
| 3-axis accelerometer | |
| Axes | X, Y, Z |
| Frequency range | 10 – 1000 Hz (datasheet; web product table lists 5 – 1000 Hz) |
| Amplitude range | ±16 g (±2 / ±4 / ±8 / ±16 g) |
| Statistical time-domain values | Velocity RMS; acceleration RMS and peak; displacement; kurtosis; crest factor; skewness; standard deviation |
| Output data rate | 6600 Hz |
| Resolution | 10 bit (all g ranges) |
| Accuracy (fc = 100 Hz) | < 5 % |
| Noise (25 °C, 0 g) | ±40 mg |
| Nonlinearity | ±0,5 % |
| Cross-axis sensitivity | ±1 % |
| Sensitivity change with temperature | ±0,02 %/°C |
| Temperature sensor | |
| Measurement range | −20…+120 °C |
| Accuracy | −2 °C at 85 °C, −5 °C at 120 °C (direct contact with heat source via metal base, TA = 27 °C) |
Key features
- LoRaWAN wireless connectivity
- Built-in 3-axis accelerometer and temperature sensor
- On-board computing: sends VRMS, ARMS, peak, displacement, kurtosis, crest factor, skewness and standard deviation directly to the application
- Battery powered — no wiring installation needed
- Easy settings with the WISE Studio utility
- ISO 10816 and ISO 20816 compliant
- Wide −20 to +80 °C temperature range (battery powered)
- IP66 enclosure
Ordering information
| Part number | Description |
|---|---|
| WISE-2410-NB | Wireless smart condition-monitoring sensor — US 902-928 MHz (optional patches: JP, AS923, KR, AU915) |
| WISE-2410-EB | Wireless smart condition-monitoring sensor — EU 863-870 MHz (optional patch: RU) |
Accessories and related products
| Part number | Description |
|---|---|
| 1760002647-01 | 3.6 V / 2500 mAh AA Li/SOCl2 battery |
| 25F7000004N000 | Magnet base D30 × H9 mm |
| WISE-2410-MTB01 | Metal mounting base |
| WISE-6610-EB / -NB / -TB / -JB | LoRaWAN gateway (EU868 / NA915 / AS923 / JP923; -EL: with Edgelink) |
Is this product right for your vibration-monitoring project?
Share the equipment to be monitored, ambient conditions (standard/Ex, temperature) and your existing infrastructure (LoRaWAN, RS-485, PLC/SCADA); let’s select sensor, gateway and communication path together.
All product specifications are subject to change without notice; data compiled from Advantech’s WISE-2410 datasheet dated 23 October 2024 and the advantech.com product page.
