ADVANTECH FPM-724W — Industrial Panels
23.8″ Full HD (1920 × 1080) widescreen P-CAP multi-touch industrial monitor — 350 cd/m², HDMI/DP/VGA inputs, IP66 true-flat front, 0 to 50 °C, 24 VDC, panel/wall/VESA mounting.
Status: In production
Product: 23.8″ industrial touch monitor — Full HD, IP66 front panel
Display: 23.8″ · 1920 × 1080 · 350 cd/m²
Touch: P-CAP 10-point (USB)
Video input: HDMI · DP · VGA
Protection: IP66 front panel · 0 to 50 °C
FPM-724W is the 23.8″ Full HD (1920 × 1080) widescreen P-CAP multi-touch industrial monitor of Advantech’s FPM-700 series: 350 cd/m² brightness, 1000:1 contrast, 178° viewing angle and a 30,000-hour backlight. The true-flat glass surface supports 10-point multi-touch; the 16:9 format gives 40 % more viewing area at the same diagonal. It is the largest screen in the series; with an anti-glare touch surface and 178° viewing angle it is intended for line-monitoring boards and control-room stations. The operating range of this model is 0 to 50 °C.
The three widescreen models share one platform: direct HDMI, DisplayPort and VGA inputs, 10-point P-CAP touch over USB (true-flat 7H glass), 1 × USB 2.0 at the rear, 24 VDC ± 20 % via terminal block and lockable connectors. Front panel and rear cover are die-cast aluminium; the front is IP66-rated. Stand/wall/panel/VESA 75 mounting and 1 Grms vibration resistance cover on-machine, line-monitoring and operator-station applications. In the ordering code, -P9AE is made in China and -P9AU in Taiwan; the 60 W adapter and its bracket are optional.
Technical specifications
| FPM-724W | |
|---|---|
| LCD display | |
| Display type | 23.8″ Full HD TFT LED LCD |
| Aspect ratio | 16:9 |
| Max. resolution | 1920 × 1080 |
| Max. colours | 16.7 million |
| Viewing angle (H / V) | 178 / 178° |
| Luminance | 350 cd/m² |
| Contrast ratio | 1000:1 |
| Backlight life | 30,000 hr |
| Touchscreen | |
| Touch type | Projected capacitive (P-CAP), 10-point multi-touch |
| Touch interface | USB |
| Surface hardness | 7H |
| OS support | Windows 7 / 8 / 10 / 11, XPe, CE and Linux (multi-touch: Windows 7/8/10, Linux) |
| Touch surface | Anti-glare |
| Interfaces and power | |
| Video ports | HDMI, DisplayPort, VGA |
| USB (rear I/O) | 1 × USB 2.0 Type A (touch) |
| Power input | Terminal block, 24 VDC ± 20 % |
| Power consumption (standby / max.) | 0.158 W / 25.47 W |
| Physical characteristics | |
| Dimensions (W × H × D) | 595.9 × 374.1 × 53 mm |
| Panel cutout | 587 × 365.3 mm (−0.4) |
| Weight (net) | 7.8 kg |
| Enclosure | Front panel and rear cover: die-cast aluminium |
| Mount options | Stand, wall, panel and VESA arm (75 × 75 mm) |
| Environment | |
| Operating temperature | 0 to 50 °C |
| Storage temperature | −30 to 70 °C |
| Relative humidity | Operating 95 % @ 40 °C, non-operating 95 % @ 60 °C (non-condensing) |
| Front panel protection | IP66 |
| Vibration | 5 – 500 Hz, 1 Grms (operating, random) |
| Certification | |
| Certification | BSMI, CCC, CE, FCC Class A, UL, CB, KC |
| Packing list | |
| In the box | Terminal block, panel clampers and screws, ground cable, USB touch cable (1.69 m), VGA cable (1.8 m), HDMI/DP lockable kit |
Key features
- 23.8″ Full HD TFT LED LCD, 350 cd/m², 30,000-hour backlight life
- Projected capacitive (P-CAP), 10-point multi-touch
- True-flat glass surface, widescreen format (40 % more viewing area)
- Die-cast aluminium chassis with IP66-rated aluminium alloy front bezel
- Lockable I/O connectors
- Slim design for easy panel installation
- Panel, wall, desktop or VESA arm mounting
Ordering information
| Part number | Description |
|---|---|
| FPM-724W-P9AE | 23.8″ Full HD industrial monitor with P-CAP touch (made in China) |
| FPM-724W-P9AU | 23.8″ Full HD industrial monitor with P-CAP touch (made in Taiwan) |
The last letter of the part number indicates the place of manufacture: E = China, U = Taiwan. The monitor has no compute of its own; the video source (box PC, PLC, IPC) is selected separately.
Accessories and optional items
| Part number | Description |
|---|---|
| PWR-247-DE | Power adapter 100 – 240 V, 60 W, 24 V / 2.5 A |
| 1702002605 | Power cable, EU plug, 1.8 m |
| 1702002600 / 1702031801-11 / 1700000596-11 | Power cable, US / UK / China-Australia plug, 1.8 m |
| FPM-200W-ADKE | Adapter bracket (datasheet; the web accessory list shows FPM-7000G-ADKE “mounting bracket of adapter”) |
| FPM-1000T-SMKE | Desktop mounting kit for FPM series |
| PPC-174T-WL-MTE | Wall mount kit (A800B) |
| PPC-ARM-A03 | VESA-standard arm (A-CLEVER) |
| PPC-STAND-A1E | Stand mounting kit |
Is this monitor right for your project?
Share the screen size and touch type (glove use → resistive, multi-touch → P-CAP), your panel cutout, ambient conditions and the video output of the computer to be connected (HDMI/DP/VGA/USB-C); let’s choose the model, mounting kit and, if needed, the box PC together. FST commissions the monitor together with the industrial computer and SCADA/HMI software as one solution.
All product specifications are subject to change without notice; data compiled from Advantech’s FPM-724W datasheet dated 8 September 2026 and the advantech.com product page.
